HMC1061

RECOMMENDED FOR NEW DESIGNS

DC to 18 GHz, Ultra Wideband, Dual Rank, 4 GSPS Track-and-Hold Amplifier

Data Sheet (Rev. B) Product Selection Table

Part Models: 3
1ku List Price: price unavailable

Viewing:

Part Details

18 GHz input sampling bandwidth (1 V p-p full-scale)
4 GSPS maximum sampling rate
67 dB SFDR at 4 GHz and 0.5 V p-p input and CLK = 1 GSPS)
56 dB SFDR at 4 GHz and 1 V p-p input and CLK = 1 GSPS)
Direct coupled input/output
Ultra clean output waveforms, minimal glitching
≥65 dB hold mode feedthrough rejection
1.45 per specs mV rms hold mode output noise
32-terminal ceramic leadless chip carrier, 5 mm × 5 mm

Part Models: 3
1ku List Price: price unavailable

Documentation

Data Sheet 1

HMC1061LC5: DC to 18 GHz, Ultra Wideband, Dual Rank, 4 GSPS Track-and-Hold Amplifier Data Sheet (Rev.B) 02/27/2018

Application Note 1

AN-1472: General Guidelines and Procedures for Using the HMC661LC4B and HMC1061LC5 with an ADC (Rev.0) 02/27/2018

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
HMC1061LC5	32-Lead LCC (4.9mm x 4.9mm)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
HMC1061LC5TR	32-Lead LCC (4.9mm x 4.9mm)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
HMC1061LC5TR-R5	32-Lead LCC (4.9mm x 4.9mm)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
