LTC1334

PRODUCTION

Single 5V RS232/RS485 Multiprotocol Transceiver

Data Sheet Product Selection Table
Viewing:

Part Details

  • Four RS232 Transceivers or Two RS485 Transceivers on One Chip
  • Operates from a Single 5V Supply
  • Withstands Repeated ±10kV ESD Pulses
  • Uses Small Charge Pump Capacitors: 0.1µF
  • Low Supply Current: 8mA Typical
  • 10µA Supply Current in Shutdown
  • Self-Testing Capability in Loopback Mode
  • Power-Up/Down Glitch-Free Outputs
  • Driver Maintains High Impedance in Three-State, Shutdown or with Power Off
  • Thermal Shutdown Protection
  • Receiver Inputs Can Withstand ±25V
LTC1334
Single 5V RS232/RS485 Multiprotocol Transceiver
