MAX7427

RECOMMENDED FOR NEW DESIGNS

5th-Order, Lowpass, Elliptic, Switched-Capacitor Filters

Industry's Lowest-Power and Industry's Smallest 5th-Order Lowpass Filters

Data Sheet (Rev. 0)

Part Models: 5
1ku List Price: Starting From $1.65

Viewing:

Part Details

5th-Order, Elliptic Lowpass Filters
Low Noise and Distortion: -80dB THD + Noise
Clock-Tunable Corner Frequency (1Hz to 12kHz)
Single-Supply Operation
- +5V (MAX7426)
- +3V (MAX7427)
Low Power
- 0.8mA (Operating Mode)
- 0.2µA (Shutdown Mode)
Available in 8-Pin µMAX®/PDIP Packages
Low Output Offset: ±4mV

Part Models: 5
1ku List Price: Starting From $1.65

Documentation

Data Sheet 1

MAX7426-MAX7427: 5th-Order, Lowpass, Elliptic, Switched-Capacitor Filters Data Sheet (Rev.0) 06/15/2000

Technical Articles 1

Generating Switched-Capacitor-Filter Clocks 11/19/2001

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX7427CPA+	Plastic Dual-In-Line, Narrow (0.3in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX7427CUA+	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX7427CUA+T	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX7427EUA+	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX7427EUA+T	Micro-MAX, Thin Shrink Small-Outline	Material Declaration Reliablity Data	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

Sep 19, 2018 - 1753N ASSEMBLY
		pcn_1753n
MAX7427EUA+	PRODUCTION
MAX7427EUA+T	PRODUCTION

This is the most up-to-date revision of the Data Sheet.

Software Resources

Can't find the software or driver you need?

Request a Driver/Software

Hardware Ecosystem

Parts	Product Life Cycle	Description
Active Filters 2
MAX7411	PRODUCTION	5th Order, Lowpass, Elliptic, Switched-Capacitor Filters
MAX7415	PRODUCTION	5th Order, Lowpass, Elliptic, Switched-Capacitor Filters
