AD822

量产

单电源、轨到轨、低功耗、FET输入双通道运算放大器

数据手册 (Rev. J)

产品模型: 12

Viewing:

产品详情

真正的单电源供电
轨到轨输出摆幅
输入电压范围扩展至地电压以下
5 V至30 V单电源供电能力
双电源供电：±2.5 V至±15 V
轨到轨输出摆幅
输入电压范围扩展至地电压以下
5 V至30 V单电源供电能力
双电源供电：±2.5 V至±15 V
高负载驱动能力
350 pF、G = +1的容性负载驱动能力
最小输出电流：15 mA
350 pF、G = +1的容性负载驱动能力
最小输出电流：15 mA
欲了解更多特性，请参考数据手册

AD822-EP支持防务和航空航天应用（AQEC标准）

下载AD822-EP数据手册(pdf)
军用温度范围（−55℃至+125℃）
受控制造基线
封装/测试厂
制造厂
增强型产品变更通知
认证数据可应要求提供
V62/12636 DSCC图纸号

参考资料

数据手册 3

AD822: Single Supply, Rail-to-Rail Low Power FET-Input Op Amp Data Sheet (Rev.J) 09/25/2015

AD822-EP: Enhanced Product Data Sheet (Rev.0) 09/25/2015

AD822-DSCC: Military Data Sheet 09/25/2015

应用笔记 2

AN-581: Biasing and Decoupling Op Amps in Single Supply Applications 09/14/2023

AN-256: Accurately Testing Op Amp Settling Times 02/14/2015
