MAX732

PRODUCTION

+12V/+15V Step-Up Current-Mode PWM Regulators

We Recommend Improved Performance Device, MAX618, for New Designs

Data Sheet (Rev. 2)

Part Models: 4
1ku List Price: price unavailable

Viewing:

Part Details

Load Currents Guaranteed to 200mA with No ExternalM OSFET (125mA tor MAX733)
170kHz High-Frequency Current-Mode PWM
Small Inductor and No Component Design Required
85% to 92% Efficiencies at Full Load
Overcurrent and Soft-Start Protection
8-Pln DIP, 18-Pln Wide 80 Packages
Step-Up from a 4.0V lnput
Shutdown Pin

Part Models: 4
1ku List Price: price unavailable

Documentation

Data Sheet 2

MAX732-MAX733: +12V/+15V Step-Up Current-Mode PWM Regulators Data Sheet (Rev.2) 03/01/1996

MAX73123: Military Datasheet 09/11/2023

Reliability Data 1

MAX732 Reliability Data 01/12/2023

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX732CWE+	Small-Outline IC, Wide (0.3in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX732EPA+	8-PDIP-300_MIL	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX732EWE+	Small-Outline IC, Wide (0.3in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX732MJA/883B	Ceramic Dual-In-Line, Narrow (0.3in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys

This is the most up-to-date revision of the Data Sheet.

Hardware Ecosystem

Parts	Product Life Cycle	Description
Switching Regulators & Controllers 1
MAX618	PRODUCTION	28V, PWM, Step-Up DC-DC Converter
